| Place of Origin | China |
| Brand Name | HORNQUIP |
| Certification | CE |
| Model Number | 936B |
| Technical specification | |
| Bucket capacity | 1-1.5 m³ |
| Rated load | 2500-2800 kg |
| Overall dimension | 6600*2100*2950mm |
| Operating weight | 6500 kg |
| Max. breakout force | 127 K.N |
| Max. dumping height | 3400 mm |
| Max. dumping distance | 1000 mm |
| Engine | |
| Engine manufacturer | Weichai |
| Model | DEUTZ WP6G125E22 |
| Rated power | 92 KW |
| Max. torque | 500 N.m |
| Steering system | |
| Type | Full-hydraulic, articulated |
| Steering angle | 34° |
| Transmission system | |
| Torque converter type | Single phase, hydraulic converter |
| Gear shift | 2 forward, 2 reverse |
| Max. speed | 25 km/h |
| Axle | 4WD, heavy hub reduction |
| Tyre size | 16/70-24 |
| Brake system | |
| Service brake | Gas cap oil disc brake on 4 wheels |
| Parking brake | Hand operated caliper disc |
